Represents the weak formulation of a PDE problem. More...

#include <weakform.h>

Inheritance diagram for Hermes::Hermes2D::WeakForm< Scalar >:

Public Member Functions
	WeakForm (unsigned int neq=1, bool mat_free=false)

	~WeakForm ()
	Destructor.

void	add_matrix_form (MatrixFormVol< Scalar > *mfv)
	Adds volumetric matrix form.

void	add_matrix_form_surf (MatrixFormSurf< Scalar > *mfs)
	Adds surface matrix form.

void	add_matrix_form_DG (MatrixFormDG< Scalar > *mfDG)
	Adds DG matrix form.

void	add_vector_form (VectorFormVol< Scalar > *vfv)
	Adds volumetric vector form.

void	add_vector_form_surf (VectorFormSurf< Scalar > *vfs)
	Adds surface vector form.

void	add_vector_form_DG (VectorFormDG< Scalar > *vfDG)
	Adds DG vector form.

unsigned int	get_neq () const
	Returns the number of equations.

bool	is_matrix_free () const

void	set_current_time (double time)
	For time-dependent right-hand side functions.

void	set_current_time_step (double time_step)

virtual double	get_current_time () const

virtual double	get_current_time_step () const

Hermes::vector< Form< Scalar > * >	get_forms () const

Hermes::vector< MatrixFormVol < Scalar > * >	get_mfvol () const

Hermes::vector< MatrixFormSurf < Scalar > * >	get_mfsurf () const

Hermes::vector< MatrixFormDG < Scalar > * >	get_mfDG () const

Hermes::vector< VectorFormVol < Scalar > * >	get_vfvol () const

Hermes::vector< VectorFormSurf < Scalar > * >	get_vfsurf () const

Hermes::vector< VectorFormDG < Scalar > * >	get_vfDG () const

void	delete_all ()
	Deletes all volumetric and surface forms.

void	set_ext (MeshFunction< Scalar > *ext)
	external functions.

void	set_ext (Hermes::vector< MeshFunction< Scalar > * > ext)

Hermes::vector< MeshFunction < Scalar > * >	get_ext () const

virtual WeakForm *	clone () const

Protected Member Functions
bool **	get_blocks (bool force_diagonal_blocks) const

Protected Attributes
Hermes::vector< MeshFunction < Scalar > * >	ext
	External solutions.

double	current_time

double	current_time_step

unsigned int	neq

bool	is_matfree

Hermes::vector< Form< Scalar > * >	forms
	Holds all forms.

Hermes::vector< MatrixFormVol < Scalar > * >	mfvol
	Holds volumetric matrix forms.

Hermes::vector< MatrixFormSurf < Scalar > * >	mfsurf
	Holds surface matrix forms.

Hermes::vector< MatrixFormDG < Scalar > * >	mfDG
	Holds DG matrix forms.

Hermes::vector< VectorFormVol < Scalar > * >	vfvol
	Holds volumetric vector forms.

Hermes::vector< VectorFormSurf < Scalar > * >	vfsurf
	Holds surface vector forms.

Hermes::vector< VectorFormDG < Scalar > * >	vfDG
	Holds DG vector forms.

bool	warned_nonOverride

Friends
class	DiscreteProblem< Scalar >

class	DiscreteProblemLinear< Scalar >

class	RungeKutta< Scalar >

class	OGProjection< Scalar >

class	Hermes::Preconditioners::Precond< Scalar >

Detailed Description

template<typename Scalar>
class Hermes::Hermes2D::WeakForm< Scalar >

Represents the weak formulation of a PDE problem.

The WeakForm class represents the weak formulation of a system of linear PDEs.
The number of equations ("neq") in the system is fixed and is passed to the constructor.
The weak formulation of the system A(U, V) = L(V) has a block structure. A(U, V) is
a (neq x neq) matrix of bilinear forms a_mn(u, v) and L(V) is a neq-component vector
of linear forms l(v). U and V are the vectors of basis and test functions.

There is a single tutorial just on implementing the weak formulation.
For some basic ideas, please see the examples provided.

Definition at line 91 of file global.h.

Constructor & Destructor Documentation

template<typename Scalar >

Hermes::Hermes2D::WeakForm< Scalar >::WeakForm	(	unsigned int	neq = `1`,
		bool	mat_free = `false`
	)

Constructor.

Parameters

[in]	neq	Number of equations.
[in]	mat_free	If this weak formulation does not include a matrix - e.g. JFNK method.

Definition at line 37 of file weakform.cpp.
